Process of Layering Sequentially to Create High-Density Interconnect Printed Circuit Boards (HDI PCBs)

Sequential layering is a method for creating compact printed circuit boards through the stacking of core materials and layers made up of copper and insulating materials.

Sequential Lamination Process for the Production of HDI PCBs
Sequential Lamination Process for the Production of HDI PCBs

Process of Layering Sequentially to Create High-Density Interconnect Printed Circuit Boards (HDI PCBs)

In the world of electronics manufacturing, sequential lamination plays a crucial role in the fabrication of High-Density Interconnect (HDI) Printed Circuit Boards (PCBs). This process, which involves building a multilayer board layer by layer, is essential for creating complex HDI structures.

The process begins with the preparation of a laminated core. Layers are then built up in stages by adding prepreg (pre-impregnated resin sheets) and copper foils. Each lamination cycle involves applying high temperature, often over 200°C, and high pressure, up to 500 psi, to cure and bond the materials. Registration accuracy is critical to ensure layers align precisely, often controlled by automated optical positioning.

After each lamination, vias (microvias, buried vias) are drilled, filled, and plated before additional layers are added. The number of lamination cycles depends on the design layer count, materials used, and reliability requirements. More layers and complex HDI structures require more sequential lamination cycles to build up layers.

The number of lamination cycles can range from 2 to more than 4, depending on the complexity of the PCB. For instance, in a sample HDI stack-up, there are blind vias from 1-2 and 15-16, and laser-drilled, buried vias lie between 2-3, 3-4, 4-5, 12-13, 13-14, and 14-15. The HDI structure also comprises a mechanically drilled buried via layers 4 to 13, requiring 4 lamination cycles.

Advanced materials and techniques aim to minimize the number of cycles while maintaining performance and yield. For example, Arlon 85 NT is a pure polyimide with a high Tg of 2500°C, reinforced with a non-woven substrate, offering high-reliability features in addition to temperature stability and low in-plane expansion. Rogers 4000 and 5000 series laminates have superior thermal conductivity, high Tg (around 2500°C), controlled dielectric constant, and thermal robustness, preferred over traditional PTFE materials for microwave and millimeter frequency applications.

Incorporating lower resin content for subsets and higher resin content for dielectrics can also help reduce the Z-axis expansion and distribute heat over a larger area. Materials like Isola-370 HR, a multifunctional FR4 epoxy resin with a glass transition temperature of 180°C and a high conductive anodic filament (CAF) resistance, are suitable for sequential lamination.

To increase the reliability of HDI boards, choose a dielectric material with high Tg (≥ 180°C) and low Z-axis expansion, and add heat sinks made of aluminum or copper. By following these practices, manufacturers can ensure the production of high-quality, reliable HDI PCBs.

In conclusion, sequential lamination is a step-wise buildup of multilayer PCBs under heat and pressure, critical for HDI PCB fabrication. The number of lamination cycles depends on the design layer count, materials used, and reliability requirements, with a trade-off between complexity and manufacturing challenges. By understanding this process and the factors influencing it, manufacturers can optimize their production processes to create high-quality, reliable HDI PCBs.

  1. A stack-up designer must consider the number of lamination cycles when designing complex High-Density Interconnect (HDI) Printed Circuit Boards (PCBs), as more cycles are required for intricate structures.
  2. The material selector in the electronics industry might choose Arlon 85 NT, a high-reliability polyimide material with a Tg of 2500°C, for its heat stability and low in-plane expansion, suitable for sequential lamination.
  3. In personal-finance management, one might consider investing in companies that specialize in data-and-cloud-computing technology, as the demand for high-quality HDI PCBs is significant in this sector.
  4. HDI PCB fabrication relies on controlled impedance and precise registration accuracy, making it an essential part of the science behind electrical engineering.
  5. The industry of home-and-garden appliances might benefit from reliable HDI PCBs, given that they often incorporate complex electronic components like temperature sensors and timers.
  6. Medical-conditions that require constant monitoring might be addressed more effectively with advanced electronics that utilize HDI PCBs, thanks to their ability to fit complex structures in a compact space.
  7. In the realm of sports-betting, high-performance gaming devices may employ HDI PCBs, ensuring a smooth and responsive user experience.
  8. For lifestyle enthusiasts who enjoy travel and shopping, HDI PCBs can be found in a variety of devices, from smartphones and laptops to smart locks and smart home solutions.
  9. The finance department of a sports company could consider investing in businesses related to technology and PCB manufacturing, given the growth and importance of this sector in modern sports equipment.
